Page 16
OWNER'S MANUAL
Press NEXT
to advance
Press NEXT
to advance
Press the PROGRAM button to exit Advanced Setup.
Indicates that the ther-
mostat jumper is set for
an O reversing valve
(energize in cooling) or
a b reversing valve
(energize in heating).
ON indicates that the
thermostat jumper is
set for Electric Heat
operation, or OFF for
Gas/Electric or Heat
Pump operation (page
18).
0
Press NEXT
to advance
Use these buttons to select
thermostat operation in
degrees F or C.
Press NEXT
to advance
Use these buttons to
adjust the Cycles Per Hour
from 2 to 6.
d=no limit (zoning)
d1=d+no compressor
lockout (page 17).
Press NEXT
to advance
6
The following three setup steps are ‘Read Only’
and may only be set with the jumpers on the
circuit board of the thermostat (see Installation
Instructions).
S1-THEM22P7S
OFF = Gas Electric
operation
ON = Heat Pump
operation
To Next Page
