Command List (By WG Keyboard)
Function Command Exposition
Real time clock setting 25 YYMMDDHHMMSS
YYMMDDHHMMSS ＝ Year/Month/Day/Hour/Min./Sec.
Anti-pass-back (Enable user) 26 SSSSS EEEEE P
SSSSS= starting user address; EEEEE= ending user address
P=0=Enable; P=1=Disable; P=2=Initial
Lift control setting: single door 27 UUUUU LL
UUUUU＝user address；LL：Floor number(01~64 oor)
Duress Function and Arming output setting 28 ???
Arming output and Duress function: ???= 008 (default value)
Delete all tag/Delete all tag + parameters setting 29 29 / 29 299
Same tag reading interval time 31 TTTT
Base on 10ms, range from 10 to 6000
Auto ring the clock alarm schedule 32 SS HHMMTT 7123456H
SS= 16 sets auto alarm schedule, range 0~15
HHMM= HH:MM (ex. 0830: Ring bell at 08:30)
TT=Period of time to ring bell
(Base on second, range 01~99 sec.)
7123456: 7 days of week -Sun/Mon/Tue/Wed/Thu/Fri/Sat
(Input value: 0=disable; 1=enable)
H: Holiday (Input value: 0=disable; 1=enable)
Holiday Setting 35 MMDD F
MM= Month of year (01=Jan...10=Oct.)
DD= Date of month (01=1st day of month)
F= 0:Delete ; 1: Add
Enabling or Disabling into Full Access status 36 MW
M=AR-331-EF ; W=WG Reader (0=disable; 1=enable)
RS485 port function setting
(Needs to be restarted after setting)
37 AB
A＝0:AR401RO B＝0: 9600(default value)
1:Host (default value) 1: 19200
2:LED Panel 2: 38400
3:Printer 3: 57600
Adding / Deleting Fingerprint 39 F UUUUU
F＝ 1: Adding one nger data / 2: Adding two nger data
3:Adding three nger data / 0: Delete
UUUUU＝user address
Deleting All Fingerprint 39 9 99999
En/Disable Skip Finger/Tag 40 F NNNNN EEEEE
First 40*1*
NNNNN*EEEEE#
Then 40*3*
NNNNN*EEEEE#
Change WG bits output format 41 n
n：0＝WG26 ； n：1＝WG34
PIN & UID Length setting
42 m n
m＝PIN code Length 4~8 Digit
n＝ UID Length 4~8 Digitn＝ UID Length 2~8 Digit
Compound Command Function List
Access mode:
FP rst and then Tag (Default Value)
setting a pair of command
setting a pair of command
Access mode: FP only or Tag only
First 40*0*
NNNNN*EEEEE#
Then 40*2*
NNNNN*EEEEE#
NNNNN= starting user address;EEEEE= ending user address
20 0 ??? (Main Controller Parameter Setting)
20
1 ??? (WG Input Port Parameter Setting)
※
Default Value
Function Option Value
Bit
Application
Entry and Exit Access is recorded on Duty Report
※
0: Yes 1: No 001 0 Networking
Activate close door automatically lock (Auto-Relock)
※
0: Disable 1: Enable 002 1 Networking/Stand-Alone
Auto Open
※
0: Disable 1: Enable 004 2 Networking/Stand-Alone
When Access Mode is "Card and PIN", Readers can skip pressing PIN code
※
0: Disable 1: Enable 008 3 Networking/Stand-Alone
Exit by Push Button 0: Disable
※
1: Enable 016 4 Networking/Stand-Alone
Enable force Open trigger alarm
※
0: Disable 1: Enable 032 5 Networking
Entry/Exit Reader
※
0: Exit 1: Entry 064 6 Networking
Anti-pass-back
※
0: Disable 1: Enable 128 7 Networking
Weighted Value Manual :
"Selection" of the function that you need is either
have 0 or 1 value.
Substract the "Value" of each Option with Selection.
Function = [0(deactive)*Value] ; [1(activate)*Value]
Add up all of the Function per Compound Command
(20 , 24 ,etc)
Step 1:
Select the "Function" that you need for each
Compound Command category (20 , 24 , etc)
Step 2:
Step 3: Step 4:
