SOYAL
ACCESS CONTROL SYSTEM
®
AR-837 (E) / (EF)
V140217
H. Arming Password
J. Duress Code
K. Terminal Port
I. Arming Delay Time
Access programming mode
→
Parameters[1]
→
Arming PWD
→
Input 4-digit PIN (0001~9999; Default: 1234)
→
Succeeded
Or via 701Server and set it on AR-829E screen
3
8
Or via 701Server to set it on AR-829E-V5 screen
※
Duress Code is only available in networking mode. It will substitute a personal pin code and send the message of Duress to computer as a
warning signal.
Access programming mode
→
Parameters[2]
→
Duress Code
→
4 sets (select one)
→
Input 4-digit PIN (0001~9999)
→
Succeeded
4 7
Access programming mode
→
Tools
→
Terminal Port
→
0:Lift ; 1:Host ; 2:LED ; 3:PRN (default value:1)
→
Baud Selection
(default value:9600)
→
Succeeded
5 4
L. Setting up the alarm / arming
Conditions:
1. Arming enabled
2.Alarm system connected
Situations:
1. Door is open overtime
: Door is open longer than door relay time plus door close time.
2. Force open
(Opened without a valid user card): Access by force or illegal procedure.
3. Door position is abnormal
: Happening when power is off and then on again, besides, reader was on arming before power went off.
Enable/Disable the arming status:
Standby Mode
Access Programming mode
Card only Card or PIN Card and PIN
Open the door
Present the tag to reader
→
Input
4-digit arming PWD
→
Input user address
→
Input
4-digit individual PWD
→ →
Input 4-digit arming PWD
→
Present the tag to reader
→
Input
4-digit individual PWD
→ →
Input 4-digit arming PWD
→
Enable:
Access programming mode
→
Quit & Arming
7
Disable:
Access programming mode
→
Quit
6
No open the door
→
Input 4-digit arming PWD
→
Present the tag to reader
Access programming mode
→
Parameters[1]
→
ArmingDelayTm
→
Enter armed sta. Delay time(Sec), Range:000~255
;
Armed pulse out-put time (10ms) ,Range
:
000~255
→
Succeeded
3
7
※
[Use FP] can substitute for [Induct valid card].
F. Adding / Deleting Fingerprint
Adding
Access programming mode
→
User Setting
→
Enroll FP
→
Key in 5-digit user address
→
1 or 2 different ngers on the sensor lens
→
Succeeded
P.S. The AR-837EF needs to collect twice for each ngerprint.
2 6
Deleting
Access programming mode
→
User Setting
→
Delete FP
→
Key in 5-digit user address
→
Succeeded
P.S. If you want to delete all users’ FP, key in
99999
2 7
#
G. Access Mode
Access programming mode
→
User Setting
→
Access Mode
→
Key in 5-digit user address (00000~08999)
→
0: Invalid; 1:Card; 2: Card or PIN; 3: Card and PIN
(
837EF
: →
Finger Identify: 0: Must ; 1: Ignore )
→
Succeeded
2
2
Access Mode Finger Identify (837EF Only) Result (837EF Only)
Hardware 701Client Hardware 701Client
0:Invalid
0: Must
Just ngerprint
Just card control
Invalid User
1: Ignore
Just ngerprint
Just card control
1:Card
0: Must
Just ngerprint
Just card control
Finger+Card
1: Ignore
Just ngerprint
Just card control
1. Card Only
2. Finger Only
2:Card or PIN
0: Must
Just ngerprint
Just card control
1. Finger+Card
2. Finger+PIN
3. Card+Finger+PIN
4. Card+Finger+Card
5. PIN+Finger+PIN
6. PIN+Finger+Card
1: Ignore
Just ngerprint
Just card control
1. Card Only
2. PIN Only
3. Finger Only
3:Card and PIN
0: Must
Just ngerprint
Just card control
Finger+Card+PIN
1: Ignore
Just ngerprint
Just card control
1. Card+PIN
2. Finger+PIN
