Soyal AR-837 E - Specialized Programming Functions; Anti-pass-back Configuration; Lift Control Setup; Single Floor Access

V140217
LCD / Biometrics Access Controller
O. Alarm Clock (for Factory)
P. OpenZone
Q. Open TimeZone
Hardware installation
M1
Board
Horn
M2
1
2
3
4
5
6
7
8
N.C.
N.O.
COM
CTL
12V
ALM
12V
GND
GND
P1
Output to
M1
and
M2
Mike device
Mike device
Music Box
Music Box
Mike's sound wire
Mike's sound wire
DC 12V Relay Board
Controller
POWER
12VDC
Access programming mode
→
Tools
→
Daily Alarm
→
Set (00~15)
→
Set Start Tm (24 Hours) ; Set Effect Sec.
(Seconds as the bell time, Range:1~255)
→
Set Weekday (0:disable, 1: enable)
→
Succeeded
5 9
Access programming mode
→
Parameters[1]
→
OnOff OpenZone
→
Main Controller Auto Open Zone (0:disable, 1:enable)
→
Open Door Imm. During Open Zone (0:No, 1:Yes)
→
WG1 Port Auto Open Zone (0:disable, 1:enable)
→
Open Door Imm. During
Open Zone (0:No, 1:Yes)
→
Succeeded
3 2
N. Lift control
[e.g.] Connect with
AR-401RO16B
to control which oor the user will be able to access. (BAUD9600)
Access programming mode
→
Tools
→
Terminal Port
→
0
：
Lift Controller
→
Baud Selection 0
：
9600
5 4
Setting Lift control
Access programming mode
→
User Setting
→
Single Floor
→
Input 5-digit user address
→
Input single oor number: 1~64
2 4
Single oor
Access programming mode
→
User Setting
→
Multi Floor
→
Input 5-digit user address
→
Select range: 1 or 2 or 3 or 4
→
Input 16 digits
multi oors number [0:disable, 1: enable]
[e.g.] Set NO. 114, can use it through the 8 F and 16F:
Access programming mode
→
User Setting
→
Multi Floor
→
114
→
1
→
0000000100000001
2
2
5
5
Multi oors
Set
Floor/ Stop
1
0
17
0
33
0
49
0
9
0
25
0
41
0
57
0
1
2
3
4
3
0
19
0
35
0
51
0
11
0
27
0
43
0
59
0
2
0
18
0
34
0
50
0
10
0
26
0
42
0
58
0
4
0
20
0
36
0
52
0
12
0
28
0
44
0
60
0
5
0
21
0
37
0
53
0
13
0
29
0
45
0
61
0
6
0
22
0
38
0
54
0
14
0
30
0
46
0
62
0
7
0
23
0
39
0
55
0
15
0
31
0
47
0
63
0
8
1
24
0
40
0
56
0
16
1
32
0
48
0
64
0
Access programming mode
→
Tools
→
Terminal Port
→
1
：
Lift Controller
(
need to use 725L485
)
5 5
Access programming mode
→
Tools
→
Open TimeZone
→
Set (00~15)
→
Time (24 Hours) ; Main Port (0:disable, 1: enable) ;
WG Port (0:disable, 1: enable)
→
Weekday (0:disable, 1: enable)
→
succeeded
5 6
While connecting with AR-721U, AR-737H/U(WG mode) and AR-661U for anti-pass-back function, the access mode must be "Card" only.
M. Anti-pass-back
Device enable
Access programming mode
→
Parameters[2]
→
Anti-pass-back
→
master controller select [1: Yes]
→
WG select [1: Yes]
4 6
Card user enable
Access programming mode
→
Add/ Delete
→
Antipass Group
→
Input 5-digit starting user address
→
Input 5-digit ending user
address
→
must select [1: Yes]
1 9
