Hardware Setup
SY-7IZB+N
11
2-3.4
IDE Device Installation (HDD, CD-ROM)
This Motherboard offers two primary and secondary IDE device
connectors (IDE1, IDE2). It can support up to four high-speed HDD
or CD-ROM.
Connect one side of the 40-pin flat cable to the IDE device (HDD or
CD-ROM) and plug the other end to the primary (IDE1) or
secondary (IDE2) directionally keyed IDE connector on the
Motherboard.
This Motherboard can support up to four HDDs.
2-3.5 Floppy Drive Installation
The system supports 5 possible floppy drive types: 720 KB, 1.2 MB,
1.44 MB, 2.88 MB, and LS-120. In addition, this Motherboard
supports a 3-mode (720KB/1.25MB/1.44MB) floppy commonly used
in Japan.
Connect one side of the 34-pin flat cable to the floppy drive and
plug the other end to the floppy drive connector on the
Motherboard.
This Motherboard can support up to 2 floppy drives.
