91518 Multigas Analyzer Service Manual 1-5
Introduction
Rear View
Figure 1-3: Rear of 91518 Multigas Analyzer
9 pin SDLC connector (J2)
RS-232 connector (J1)
SDLC terminator
Equipotential ground terminal
26-pin SDLC connector (J3)
Power connection
