Spaceman 6235A-C - Page 9


a. Remove beater assembly from cylinder.
b. Remove scraper blades from beater
assembly; separate scraper blade clips from
scraper blade.
c. Pull o beater shoes.
d. Remove drive sha from inside cylinder
using a dry towel.
e. Separate seal from drive sha.








a. Remove beater assembly from cylinder.
b. Remove seal from beater assembly.
 

a. Remove beater assembly from cylinder.
b. Remove blades from beater assembly.
c. Remove drive shas from inside cylinder
using a dry towel.
d. Separate seal from drive sha.
 








