SPALDING 2622007 - Page 30

Parts List
30
Item Qty Part No. Description Item Qty Part No. Description
1 1 600336 Base, (Black) 27 1 108163 Pole Mount Bracket
2 1 10884401 Wheel Axle 28 2 208510 Bolt, Carriage, 5/16-18 × 4.25 in Long
3 2 266200 Wheel, 10 cm / 4 in 29 1 201683 Spacer 0.53 I.D. × 1.50 Long
4 1 901704 Top Pole Section - Black 30 1 208760 Spring, Black, Slam Jam
5 1 901703 Middle Pole Section - Black 31 1 200318 Bracket, Reinforcement, Slam Jam
6 1 901702 Bottom Pole Section - Black 32 1 900033 Bracket, Slam Jam
7 2 208860 Dual-ended Stud, 3/8-16 33 1 206048 T-Bolt, 3/8-16 × 3.25 Long
8 1 600343 Trigger, Elevator 34 1 206990 Reinforcement Bracket
9 4 203063 Nut, Nylock, 3/8-16 35 1 203470 Washer, Flat, Slam Jam
10 2 901006 Tank Strut - Black 36 1 203795 Nut, Special
11 1 203147
Bolt, Hex Head,
5/16-18 × 4 in Long
37 2 208829 Plug, Tube, Snap In, 1 in,Black
12 10 203218 Washer, Flat, 5/16 I.D. 38 4 208828 Plug, Tube, Snap In, 1.25 in, Black
13 2 203099 Nut, Nylock, 5/16-18 39 1 901536 Frame, Base Support
14 4 203679 Bolt, Hex, 3/8-16 × 2.0 Long 40 5 206340 Nut, Nylock, 1/2-13
15 2 203798
Bolt, Hex Flange,
5/16-18 × 1.5 Long
41 2 901881 Elevator Tube, Lower - Black
16 8 203100 Nut, Hex Flange, 5/16-18 42 2 901882 Elevator Tubes, Upper - Black
17 4 204962
Bolt, Hex,
5/16-18 × .625 Long
43 3 205678 Bolt, Hex, 1/2-13 × 7 in Long
18 1 202739 Bolt, Hex, 5/16-18 × 1.75 Long 44 2 206279 Bolt, Hex, 1/2-13 × 6.5 in Long
19 2 108183 Wheel Bracket 45 2 208452 Gasket, Screw Cap
20 8 201651 Spacer, 0.50 ID × 0.25 Long 46 1 Pole Pad
21 1
500065/
FR500065
Label, Height Adjustment and
Moving, English/French
47 1 901967 Cover Plate, Rim
22 1 600362 Cap, Oval Pole Top 3.5 in 48 2 209290 Screw, #10-0.394 in Long
23 2 600272
Cap, Base, Screw Cap, Large,
5.5 in Dia.
49 2 265533 Spacer, 0.5 in ID × 0.13 in Long
24 1 203617 Cap, Base 50 1 108181 Plate, Pole Mounting
25 1 Arena Slam™ Rim 51 4 208892
Bolt, Hex Flange, 5/16-18 × 1.625 in
Long
26 1 Net 52 2 901508 Tube, Vertical Elevator, Gas Strut
