Specialized EPIC - Internal Cable Routing for Carbon Frame

11
S
T
11
 Install the bolt (S) through the washer (T) and the brake mount bolt hole, then thread into the Brain reservoir.
Lightly hand tighten the bolt.
1
1
1
2
2
100% BACK
3mm FORWARD
12
 Gently pull the Brain assembly all the way to the back of its adjustment range (1), then push it forward 3mm (2).
Tighten the lower bolt first, then the upper bolt. Torque both bolts to 43 in-lbf / 4.8 Nm.
