Technical data
04/2019 EN 47
Normblock Multi 125/250
BG 160 M
11,0 kW
BG 160 L
15,0 kW
BG 180 M
18,5 kW
BG 180 L
22,0 kW
a1 210 254 241/279 241/279
b 254 254 279 279
e 256 300 328 328
f 300 300 339 339
h 160 160 180 180
h1 18 18 20 20
r 308.4 308.4 308.4 308.4
s 15 15 15 15
t 355 355 355 355
u 286.1 286.1 286.1 286.1
v 140 140 140 140
w 259.5 259.5 259.5 259.5
x 367.5 367.5 380.5 380.5
y 396.5 396.5 466 466
z 262.5 262.5 262.5 262.5
D1 Ø 350 Ø 350 Ø 350 Ø 350
L 893.5 953.5 957.5 987.5
Wei
g
ht [k
g
] 148 165 230 235
Flanges compatible with
Sa
EN 1092-2 (PN16) ASME
DN Ø 150 Ø 150 (6“)
D Ø 285 Ø 285
k Ø 240 Ø 241.3
d2 Ø 22.4 Ø 22.4
Da
EN 1092-2 (PN16) ASME
DN Ø 125 Ø 125 (5“)
D Ø 254 Ø 250
k Ø 210 Ø 215.9
d2 Ø 19 Ø 22.4
