EN
SELECT
Use the Model Select menu to
change the model memory, to assign
a model name or to copy a model.
The DX4R PRO has 50 model
memories available.
CAUTION: NEVER change
the model in Model Select while
operating a model. Changing the
model memory interrupts the
transmitter signal to the receiver
and may cause loss of vehicle
control, damage or personal injury.
NAME
Enables you to name the selected
model memory using up to ten
characters.
1. Use the roller to select
a Model Name in the List.
2. Select the character you
want to change. A list of
characters appear.
3. Select the character you
want to use.
4. When you are finished naming
the model memory, select the
arrow to save the name and
return to the list.
COPY
The Copy function shares active
model memory settings with a
selected model memory space.
This is useful for saving setups
for one model to adjust program-
ming for track conditions or
model setups.
Choosing No returns to the List
Screen. Choosing Yes saves the
active model settings to the
selected model memory.
A. Active or source model
memory number
B. Destination model memory number
IMPORTANT: When using the Copy function, model information
will be permanently overwritten by the active model settings.
A
B
MODEL SELECT
Channel Top Bottom
Steering L (left) R (right)
Throttle B (brake) F (forward)
Aux 1 H (high) L (low)
Aux 2 H (high) L (low)
TRAVEL
The Travel function supports precise endpoint adjustments in all channels. Travel values range from
0–150% (Default is 100%).
NOTICE: Always check the control directions at the extents of travel to be sure the linkages do not
bind. Travel values that are too high will cause binding, which may result in damage to the vehicle.
