1.
Remove the batteries from the transmitter. This prevents the
possibility of accidentally causing a short during the conversion.
2.
Using the 3/32-inch hex wrench, remove the three screws
on the front of the steering housing as shown. Carefully remove
the steering mechanism and unplug the steering connector.
Also remove the steering shell but leave the backplate.
3.
Using the 3/32-inch hex wrench, remove the three screws on the
front of the steering dropdown as shown. Select the appropriate
Left/Right standard steering spacer and pass the steering wheel
mechanism connector through the hole in the shell.
4.
Connect the steering wheel mechanism connector to the
connector from the transmitter being sure the connection
is tight. Note correct polarity. Fit the backplate in place and
secure the standard steering wheel assembly using the
three long cap screws.
CHANGING FROM DROPDOWN TO STANDARD WHEEL
The DX4R PRO comes with the dropdown wheel installed and can be switched to the standard wheel. All the parts necessary to
convert to the standard wheel are included. The included 3/32-inch hex wrench and a small Phillips screwdriver will be needed.
