SpeedyBee F405 WING MINI - Method 2, Soldering; FC Front Soldering Connections; Power Supply Configuration

FC Front
Method 2, Soldering
Power Supply
The layout for the F405 WING MINI is as follows
GPS without compass
Suppos dual cameras
with switching
MS4525DO
GND
SDA
SCL
5V
Both HD VTX and Analog
VTX share Vv G T5 solder pad
Digital airspeed sensor solder pad
For analog airspeed, share 4V5
and GND, and connect to AR
solder pad
Analog VTX
HD VTX
POWER
GND
RX
TX
GND
HDL
PDB Board
FC Board
FC BEC
5.2V 2A
SEVRO BEC
5V 4A
6V optional
Seo BEC
Power
Supply Jumper
Diode2A
Max
5V solder
pad
Vx solder
pad
Vv power
supply
4V5 solder
pad
Onboard Chip
VTX Power
Supply Jumper
Batte input
1，FC BEC default output is 5.2V, supplied in two routes:
·The rst route is directly supplied to the 5V solder pads.
·The second route is supplied through a diode to the onboard chip and the
4V5 solder pads.
Please note that FC BEC can provide 2A continuous current and 3A peak cur-
rent. The onboard chip requires power ≤ 1A, GPS and receiver ≤ 0.1A, and wire-
less controller ≤ 0.1A. If connecting high-power telemet or VTX to the 5V
solder pads, ensure the operating current is ≤ 0.8A.
2，The VTX power supply inteace (Vv) can be set to two power ways: direct
batte power or internal BEC 5V (shared with 5V4A Seo BEC).
·Facto setting is batte power, where Vv inteace voltage is the same as
the batte voltage.
Please note: Ensure the voltage of VTX and camera power supply matches the
batte voltage, if not, damage may occur.
·By using VTX Power Supply Jumper, you can switch to 5V power supply. In
this case, the Vv inteace voltage will be 5V (if you choose this method, ensure
the seo and VTX current are sucient).
Please note: When Seo BEC Voltage Jumper is switched to 6V, the Vv inter-
face voltage also switches to 6V.
3，Seo power supply (Vx pin header) defaults to being powered by Seo
BEC at 5V. When Seo BEC is switched to 6V via Seo BEC Voltage Jumper,
the voltage at the Vx pin header also switches to 6V.
Please note that if the ESC suppos BEC output, do not connect the BEC red
wire to the Vx pin header. Otherwise, it may damage the ESC or Seo BEC.
Alternatively, you can directly power it using the ESC's BEC, but you need to
disconnect Seo BEC Power Supply Jumper. In this way, the power supply for
the Vx pin header comes from an ESC's BEC.
4，Power supply recommendations:
·When using a digital VTX with a wide voltage input, you can use the default
batte voltage for Vv.
·When using an analog VTX powered by 5V, you can switch Vv power supply
voltage to Seo BEC's 5V supply. In this case, you can install up to four 9g
seos to avoid insucient current.
·When using aircraft with 64 or 70 EDF Jets, Seo BEC power supply may not
be sucient for seos and landing gear. You can disconnect Seo BEC Power
Supply Jumper and directly use the ESC's BEC to power the devices.
