3
SPEKTRUM DX5 PRO • TRANSMITTER INSTRUCTION MANUAL
EN
TABLE OF CONTENTS
BOX CONTENTS
The DX5 Pro transmitter is compatible with Spektrum
™
DSMR
®
and DSM2
®
Receivers.
The DX5 Pro is available with or without a receiver, both versions
are covered in this manual
• SPM5010 includes the SR2100 DSMR receiver
• SPMR5010 does not include a receiver
GETTING STARTED
SPECIFICATIONS
DX5 PRO
Type Pistol Grip Transmitter
Channels 5
Frequency 2405 – 2476 MHz
Power output (EIRP) ≤ 20 dBm
Input Voltage 4-8.4V, 4 AA alkaline batteries included
Compatibility DSM2 and DSMR
SD Card Compatible Micro SD Card, not included
DAILY DRIVING
(SR2100 Recevier)
1. Install batteries in transmitter
2. Insert bind plug in receiver and then turn on vehicle
3. Turn the transmitter on and put it in bind mode
4. Set up servo reverse, travel, and sub trim
5. Re-bind to set proper failsafe positions
1. Turn on transmitter fi rst
2. Turn on vehicle
3. Turn off vehicle fi rst
4. Turn off transmitter
Identifying Controls and Switches ....................................4
Main Screen .......................................................................4
Installing Batteries ............................................................4
Micro SD-Card ...................................................................5
R
egistering the Transmitter ..............................................5
Updating Raceware
™
Software .........................................6
Navigation ..........................................................................7
Function List ......................................................................8
Model Select .....................................................................8
Model Name .....................................................................8
Servo Setup ......................................................................8
Travel ...............................................................................8
Sub-Trim ..........................................................................9
Reverse ............................................................................9
Speed ...............................................................................9
Rates ................................................................................9
Exponential ......................................................................10
Timer...............................................................................10
Frame Rate: ....................................................................10
Failsafe ............................................................................10
Binding ............................................................................11
Mixing .............................................................................11
AVC Programming Menu ...................................................13
AVC Tuning (AVC Receiver not included) .............................14
Automatic Braking System (ABS) .......................................15
Idle Up .............................................................................15
Traction ...........................................................................15
Trim setup .......................................................................15
Trim Assign ......................................................................16
Aux Assign .......................................................................16
Telemetry .........................................................................16
Drive Mode ......................................................................17
Lap Timer ........................................................................17
System Settings ................................................................18
Display ............................................................................18
Trims ...............................................................................19
Sound settings .................................................................19
About ..............................................................................19
Calibrate ..........................................................................19
Model Select ....................................................................20
Model Utilities ..................................................................20
System Setup ....................................................................21
Create new model ............................................................21
Delete Model ...................................................................21
Model Copy .....................................................................21
Reset Model .....................................................................21
Sort Model List .................................................................22
Transfer sd card ...............................................................22
Physical Transmitter Adjustments ...................................23
Changing grips .................................................................23
Dropdown steering wheel options ......................................24
Standard wheel conversion: ..............................................24
Steering Wheel Wedges ....................................................24
SR2100 Receiver ...............................................................25
Optional Lithium Battery ..................................................26
Troubleshooting Guide ......................................................27
Optional parts list .............................................................27
FCC Information ................................................................29
IC Information ...................................................................29
Compliance Information for the European Union ............29
57840 SPM DX5 Pro DSMR Tx Manual_BOOK 357840 SPM DX5 Pro DSMR Tx Manual_BOOK 3 4/26/18 2:56 PM4/26/18 2:56 PM
