5
SPEKTRUM DX5 PRO • TRANSMITTER INSTRUCTION MANUAL
EN
REGISTERING THE TRANSMITTER
MICRO SD-CARD*
Exporting the transmitter serial number to the Micro SD-
Card allows you to upload the serial number directly into the
registration screen at www.spektrumrc.com.
To export the serial number:
1. Install the Micro SD-Card in the card reader slot located
behind a small rubber door on the back of the transmitter
2. Click the scroll wheel to enter the
FUNCTION LIST.
3. Scroll down to the System Settings
menu. Click the scroll wheel once to
open the menu.
4. Scroll to About and click the scroll
wheel once to open the menu.
5. When the Serial Number screen
appears, select EXPORT.
6. Power off the transmitter and remove
the Micro SD-Card from the transmitter.
To Upload the serial number to www.spektrumrc.com:
1. Insert the Micro SD-Card in your computer and check the contents
of the SD card on your computer for a “My_DX5R.xml” fi le.
2. In your favorite browser navigate to www.spektrumrc.com and fi nd
the Product Registration link on the top of the page as shown.
3. If you do not already have an account, create one now. If
you have an account, login in with your secure login.
4. Once logged in, go to the “My Spektrum” page. Fill out
all relevant information. Once you select your transmitter
model from the pull down menu you will be asked to
upload the serial number.
5. Click on the Select button to navigate to the “My_DX5R.
xml” fi le on the Micro SD-Card that is in your computer’s
SD card reader and select the fi le.
6. Click on the Upload from xml fi le... button and the serial
number will populate into the Serial Number fi elds.
7. Click Register at the bottom of the screen to fi nish
registering your new Spektrum Transmitter.
8. Alternatively, you can copy the serial number from the .xml
fi le and paste directly into the Serial Number fi eld.
Screen shots from www.spektrumrc.com are correct at the
time of printing but may change at a future date.
Installing the Micro SD-Card
A Micro SD-Card (not included) enables drivers to:
• Import (copy) models from any compatible Spektrum™
RaceWare™ transmitter
• Export (transfer) models to any Spektrum RaceWare transmitter
• Update Firmware in the transmitter
To install the Micro SD-Card:
1. Power off the transmitter.
2. Install the Micro SD-Card in the card reader slot located
behind the small rubber door on the side of the transmitter.
*For more Micro SD-Card information see the Transfer SD Card section.
SD card must be Class 6 or
lower, and 32GB or smaller,
formatted to FAT or FAT32.
