SPEKTRUM DX8G2 • TRANSMITTER INSTRUCTION MANUAL
EN
V-Tail Differential

OnlyavailableinSailplaneTypewhenV-TailAorV-TailBisactive.SeeSAIL (Sailplane) section for set up.
Camber Preset

OnlyavailableinSailplaneTypewhena2+aileronwingtypeisselected.SeeSAIL (Sailplane) section for set up.
Camber System

OnlyavailableinSailplaneTypewhena2+aileronwingtypeisselected.SeeSAIL (Sailplane) section for set up.
Flap System

OnlyavailableinAirplaneTypewhenaap-enabledwingtypeisselected.SeeACRO (Airplane) section for set up.
Pitch Curve

OnlyavailableinHelicopterType.SeeHELI (Helicopter) section for set up.
Swashplate

OnlyavailableinHelicopterType.SeeHELI (Helicopter) section for set up.
Gyro

OnlyavailableinHelicopterType.SeeHELI (Helicopter) section for set up.
Tail Curve

OnlyavailableinHelicopterType.SeeHELI (Helicopter) section for set up.
Motor Cut

OnlyavailableinMulticopterType.SeeMULTI (Multicopter) section for set up.
Motor Curve

OnlyavailableinMulticopterType.SeeMULTI (Multicopter) section for set up.
The following menu options are only available when they are enabled from the Model Type screen.
Mixingallowscontrolinputforachanneltoaffectmorethanone
channelatatime.Mixingfunctionssupport:
• Mixingachanneltoanotherchannel.
• Mixingachanneltoitself.
• Assigningoffsettoachannel.
• Linkingprimarytosecondarytrim.
These mixes are available for each model memory:
Select a channel for master and slave. Inputs for the
master channel control both the master and slave channels. For
example,ElevatortoFlapmakeselevatorthemasterchanneland
flap the slave channel.
Offset
ChangetheOffsetvaluetomovetheeffectivecenterposition
of the slave channel. Positive or negative value determines the
directionoftheoffset.Offsetisnotavailableforcurvemixes.
Trim
If the master channel trim should also adjust the slave channel, set
Trim to Act. A channel monitor on the left side of the screen
shows how channels respond to input. To view a switch-assigned
mixonthemonitor,themixswitchmustbeintheactiveposition.
• 8programmablemixes
• Cyclic to Throttle (HELI)
• Swashplate (HELI)
• ElevatortoFlap(ACRO)
• AilerontoRudder(ACRO)
• RuddertoAileron/Elevator(ACRO).
• Aileron>Rudder (SAIL)
• Aileron>Flap (SAIL)
• Elevator>Flap (SAIL)
• Flap>Elevator (SAIL)
If you wish to assign a mix to a switch position:
1.Makesureyouareinthedesiredmixscreen.
2.Movetheswitchyouwanttoassignthemixto.
3.Scrolltotheswitchpositionwhereyouwantthemixtobe
active.
4.Pressthescrollwheeltoactivatethemix.Whentheboxis
lled,themixisactive.
ThemixisActivewhentheboxislledandInactivewhenthe
boxisopen.Youcanassignamixtobeactiveinmultipleswitch
positions (0,1 or 2).
Tip: Use Auto Switch Select to select the switch.
CAUTION: Always do a Control Test of your model after
changingmixes.
FUNCTION LIST
Mixing
Assigning a Mix to a Switch
