Spektrum DX8G2 User Manual

44
SPEKTRUM DX8G2 • TRANSMITTER INSTRUCTION MANUAL
EN
TheAircraftOptionsmenuallowsyoutoselectacameragimbal
axis.SelectNone,1–Axis,2–Axisor3–AxisfromtheCamera
Optionsbox.
The model icon can be changed by selecting the icon and
scrolling left or right to select.
By default Trims are setup for F Mode.
F Mode trim type enables you to save trim values for individual
ightmodesifyound,forexample,theaircraftrequiresRolltrim
in Flight Mode 1 but not in Flight Mode 2.
By default switch B is assigned 3 Flight Modes. You can assign up
to five flight modes using any combination of up to two switches.
Channel Assign
Scroll and Select Channel to assign channel inputs and outputs for
each Flight Mode. Each channel can be assigned any switch on the
transmitter including but not limited to trim switches, gimbals and the
Clear/Back buttons.
Example: Assign Flight Mode 1 to be your primary flight mode where
yourgimbalscontrolprimaryightaxis.SwitchingtoFlightMode2,
youcanhavethegimbalscontrolthecameraaxisandthetrimbuttons
controlprimaryightaxis.
Tip: You can also access the Channel Assign from the Channel
Assign Menu in System Setup.
Multirotor Model Type
NOTICE: Refer to your multirotor manual for programming recommendations.
CAUTION: Always do a Control Test of your model with the transmitter after programming to make sure your model responds
as desired.
MULTI (MULTIROTOR)
F-Mode Setup
Trim Setup
Multirotor Image
IntheAircraftOptionsScreen,rolltotheimage.Clickonceonthe
image and roll the roller left or right for optional images.

Spektrum DX8G2 Specifications

General

Modulation	DSMX
Proper use	Airplane, Aircraft
Product type	Remote control
Rubber grips	Yes
Product color	Black
Frequency band	2.4 GHz
Channels quantity	8 channels
Brand compatibility	Any brand
Display type	LCD
Battery capacity	2000 mAh
