Spellman SL Series - Figure 5.7 Instant on Option; Figure 5.8 Bipolar Master;Slave Option

SL SERIES MANUAL 27 118006-001 REV Y
14
15
16
17
TB1/J5
Existing jumper
Jumper TB1 15 to 16
for Instant ON option
1
2
3
4
TB1/J5
P.S.
5
6
7
8
9
10
11
12
INSTALLATION NOTE
1
2
3
4
TB1/J5
5
6
7
8
9
10
11
12
Keep Interconnecting Wires as Short as possible.
Use of Twisted Wire Pair or Shielded/Coaxial wire is recommended.
Common
P.S.
Common
kV Test
Point OUT
Remote Voltage
Program IN
POSITIVE (MASTER)
SUPPLY
NEGATIVE (SLAVE)
SUPPLY
* REMOVE
JUMPER
LINKING
10-11
Figure 5.7 -- Instant ON
Figure 5.8 -- Bipolar/ Slave Option
