101501-565 Rev C Page 44 of 58
6.6.6 Request Miscellaneous Analog Monitor Readbacks
Description:
The host requests that the firmware transmit the present values of
Miscellaneous Analog Monitor Readbacks.
Direction:
Host to supply
Syntax:
<STX><20><,><CSUM><ETX>
Response:
If an error is detected, the Power Supply responds with:
<STX>20,!,<ERROR>,<CSUM><ETX>
Please reference the Error Code section for a list of valid error codes.
If the message is accepted, the Power Supply responds with:
<STX>20,<ARG1>,<ARG2>,<ARG3>,<ARG4>,<ARG5>,<ARG6>,<ARG7
>,<ARG8>,<CSUM><ETX>
Where:
<ARG1> = Remote Over Voltage Protection
<ARG2> = Spare
<ARG3> = Power Reference
<ARG4> = Power Monitor
<ARG5> = Control Board Temperature
<ARG6> = Spare
<ARG7> = Spare
<ARG8> = Spare
Range:
Valid values are 0 - 4095 in ASCII format.
Example Response:.
<STX>20,2048,0,4095,4095,1023,0,0,0,<CSUM><ETX>
