2010 Geno/Grinder
Page 16 of 28 SPEX® SamplePrep LLC July 2014
6.1.2 Titer Plates (Cont’d)
Double-sided nesting tray
Single-sided nesting tray
Figure 9 – Nesting Plate in Clamp Base
Figure 10 – Stacking Titer Plates
Figure 11 – Closed Clamp with 4 Titer Plates
