Spirax Sarco Colima Visco - Body Sizes and End Connections; Side Process Connections (Types LL, LF, LT); Top and Bottom Process Connections (Types TF, LF, LT); Connection Type R

Colima Visco and Viscorol Magnetic level indicators
TI-P329-01
CH Issue 1
Page 2 of 8
Connection type R
External diameter flange: minimum 100 mm
Side process connections (types LL, LF, LT)
Please note that other screwed and flanged connections are available on request.
Flanged (FL) EN 1092 and ASME (ANSI)
EN 1092
UA DN20 PN16
UB DN20 PN40
UC DN20 PN64
UD DN20 PN100
UE DN25 PN16
UF DN25 PN40
UG DN25 PN64
UH DN25 PN100
UI DN40 PN16
UL DN40 PN40
UM DN40 PN64
UN DN40 PN100
Screwed (TH)
GK M
GA ½"
GB ¾"
GC 1"
GD 1½"
NPT-M
NA ½"
NB ¾"
NC 1"
ND 1½"
ASME
AA ¾" Class 150
AB ¾" Class 300
AC ¾" Class 600
AD ¾" Class 1500
AE 1" Class 150
AF 1" Class 300
AG 1" Class 600
AJ 1" Class 1500
AK 1½" Class 150
AH 1½" Class 300
AI 1½" Class 600
AL 1½" Class 1500
Socket weld
(SW) or Butt weld (BW)
SW
SA ½"
SB ¾"
SC 1"
SD 1½"
BW
BA ½"
BB ¾"
BC 1"
BD 1½"
Top and bottom process connections (types TF, LF, LT)
Please note that other screwed and flanged connections are available on request.
Flanged (FL) EN 1092 and ASME (ANSI)
EN 1092
UA DN50 PN16
UB DN50 PN40
UC DN50 PN64
UD DN50 PN100
UE DN65 PN16
UF DN65 PN40
UG DN65 PN64
UH DN65 PN100
UI DN80 PN16
UL DN80 PN40
UM DN80 PN64
UN DN80 PN100
Screwed (TH) on the counterflange
GK M
GA ½"
GB ¾"
GC 1"
NPT-M
NA ½"
NB ¾"
NC 1"
ASME
AA 2" Class 150
AB 2" Class 300
AC 2" Class 600
AD 2" Class 1500
AE 2½" Class 150
AF 2½" Class 300
AG 2½" Class 600
AH 2½" Class 1500
AI 3" Class 150
AJ 3" Class 300
AK 3" Class 600
AL 3" Class 1500
Socket weld
(SW) or Butt weld (BW) on the counterflange
SW
SA ½"
SB ¾"
SC 1"
BW
BA ½"
BB ¾"
BC 1"
Body sizes and end connections
Flanged, screwed, socket weld and butt weld
DN20, DN25, DN40, DN50, DN65 and DN80
½", ¾", 1", 1½", 2", 2½" and 3"
