Product selection and order placement
Each unit is identified by a unique alphanumeric code that defines the manufacturing characteristics that best suites the application.
Please confirm the following information before commencement of the product configuration.
Process pressure = Process temperature =
Design pressure = Design temperature =
Fluid type =
Specific gravity of fluid =
Viscosity of fluid =
Range Colima Colima
Model
V Visco
V
R Viscorol
Type
LL Side / side mounted
LL
LF Side / base mounted
LT Side / top mounted
TF Top / base mounted
R Top insertion only
GV only Colima Visco type
GDV only Colima Visco type
Body diameter
Ø 25 (only R type)
60
Ø 50
Ø 60
Ø 70
Indicator body material
Steel
2
1 304L stainless steel (-25°C to 350°C)
2 316L stainless steel (-25°C to 350°C)
3 316Ti stainless steel (-25°C to 350°C)
Plastic
4 PVC (-20°C to 70°C)
5 PP (-20°C to 105°C)
6 PVDF (-20°C to 135°C)
Centre-to-centre measurement Insert required distance 700
Scale
N Neutral (no indication)
G Graduated (every 10 mm)
V Volumetric (customer to specify)
Connection type
FL Flanged
FL
TH Screwed
SW Socket weld
BW Butt weld
Attachment rating UA UA
Float material
A 316L stainless steel (-25°C to 350°C)
A
B 316Ti stainless steel (-25°C to 350°C)
C Titanium (-25°C to 350°C)
D Hastelloy (-25°C to 350°C)
E PVC (-20°C to 70°C)
F PP (-20°C to 105°C)
G PVDF (-20°C to 130°C)
H Buna N (-20°C to 80°C)
Valves
A Drain valve
A
B Vent valve
Electrical equipment switches
1 SPDT
2
2 DPDT
SPDT contact number from 1 up to 8
DPDT contact number from 1 up to 4
Electrical equipment transmitter
T5 5 mm
T10-A-C3
T10 10 mm
T20 20 mm
A Housing for safe area (weatherproof)
C Housing for safe area, low / high temperature
B Housing for hazardous area (ATEX II ½ G EEX d IIC)
C3 Converter for safe area
C4 Converter for in built safe area (intrinsically safe)
C5 Converter HART
®
protocol (intrinsically safe)
Isolation valve
(wafer type)
F Flanged
F
T Threaded
C Carbon steel body, st. st internals
S
S Complete stainless steel
Isolation valve quantity Q Quantity Q2
How to order example: 1 off Spirax Sarco Colima Visco V-LL-60-2-700-FL-UA-A-A-2-T10-A-C3-F-S-Q2.
