SPL Phonitor 2 - IR Remote Control Configuration; Remote Command Learning Process

24
IR Remote control
The volume potentiometer can be remotely controlled using any infrared (IR) remote control.
The special feature is that the Phonitor learns your remote and not the other way around. You do not need a learn-
able remote control. Take, for example, the remote control of the CD player. Out of the many buttons there are two
you hardly use if at all. Assign Volume up / Volume down to these two buttons and let the Phonitor learn them.
• While learning the IR remote control commands set the Output switch () to Mute.
VUmeters light up red.
• Press the IR REMOTE LEARN button () on the rear of the unit. The Power LED now lights up
brighter.
• Point your remote control towards the VU meters () and push the button you wish to use
to lower the volume. The power LED lights up once per push. Press the same button repeatedly until the
power LED lights up three times within a short interval – programming this button is then completed.
• Point your remote control towards the VU meters () and push the button you wish to use to increase the
volume. The power LED lights up once per push. Press the same button repeatedly until the power LED
lights up three times within a short interval – programming this button is then completed.
(Learn mode ends automatically after the second button is learned.)
Output
Mute
Cr/A All
Matrix
Off
IR REMOTE
IR REMOTE
OUTPUT
OUTPUT
L
R
R
L
LEARN
RLRLRL
SOURCES
SOURCES
2
2
LR
1
1
LR
Learning Volume Up/Down:
1. Press LEARN button below
2. Point your remote at VUs
and press a button for
VOLUME DOWN (LEDs flash 1x)
3. Repeat until LEDs flash 3x
4. Press a button for
VOLUME UP (LEDs flash 1x)
5. Repeat until LEDs flash 3x
XLRs: balanced, Pin 2 = Hot (+)
For unbalanced operation
bridge Pin 3 to GND.
RCAs: Unbalanced, Tip = Hot (+)
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
ON BOTTOM SIDE:
DIP SWITCH WIRING
This output can also drive balanced headphones
(Gender changer may be required).
3
3
Phonitor 2
~ 115V AC / ~230V AC
50 Hz / 60 Hz, P max. 35 W
Fuses:
Voltage Selection:
115V AC: T 1 A L 250 V
230V AC: T 500 mA L 250 V
1. Remove Fuse Holder
2. Flip Over 3. Reinstall
1 ON: Output +12dB
2 ON: Output + 6dB
3 ON: RCA -10dBV to +4dBu
4 ON: Sources 1:1 to Output
Serial
Number
Made in Germany
