SPL Phonitor 2 - Rear Panel Connections; Power Input and Mains Switch; Audio Input and Output Ports; IR Remote Learning Button

6
Rear view
IR REMOTE
IR REMOTE
OUTPUT
OUTPUT
L
R
R
L
LEARN
RLRLRL
SOURCES
SOURCES
2
2
LR
1
1
LR
Learning Volume Up/Down:
1. Press LEARN button below
2. Point your remote at VUs
and press a button for
VOLUME DOWN (LEDs flash 1x)
3. Repeat until LEDs flash 3x
4. Press a button for
VOLUME UP (LEDs flash 1x)
5. Repeat until LEDs flash 3x
XLRs: balanced, Pin 2 = Hot (+)
For unbalanced operation
bridge Pin 3 to GND.
RCAs: Unbalanced, Tip = Hot (+)
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
RISK OF E LECT RIC SHOCK
DO NOT OPEN
CAUTION
ON BOTTOM SIDE:
DIP SWITCH WIRING
This output can also drive balanced headphones
(Gender changer may be required).
3
3
Phonitor 2
~ 115V AC / ~230V AC
50 Hz / 60 Hz, P max. 35 W
Fuses:
Voltage Selection:
115V AC: T 1 A L 250 V
230V AC: T 500 mA L 250 V
1. Remove Fuse Holder
2. Flip Over 3. Reinstall
1 ON: Output +12dB
2 ON: Output + 6dB
3 ON: RCA -10dBV to +4dBu
4 ON: Sources 1:1 to Output
Serial
Number
Made in Germany
PGM
Mains Switch
15
Mains Voltage
16
Analog Audio Inputs
17
Audio Outputs
19
