Field Descriptions
Installation and Maintenance Manual v4/0615/10 335
NAT Mode
Static
Use IP address entered above
STUN
Use the name of the STUN server enter above
Use TCP
Enable/Disable. Allows the use of TCP rather than UDP (default).
No Progress
Enable/Disable. If enabled this option will stop SIP PROGRESS messages being sent.
Options Ping Disable
Enable/Disable. If enabled the Options Ping facility is disabled.
If a SIP trunk is configured for IP address authentication only (no username/password) the Options Ping is
used as a “keepalive” mechanism and provides a facility whereby the Call Server will know that the link
has gone down when there is no response to the Options Ping. This field gives the ability to disable this
in case the SIP provider does not support it.
Called Party ID disable
To be advised
Receive on Port
Default = 5060
Registrar DNS/IP Address
Address provided by SIP provider
Registration User Name
User Name provided by SIP provider. If this field contains an at sign (@) only the text prior to the @
symbol will be used in the “To:” and “From:” fields
Registration Password
Password provided by SIP provider
SIP “From” Field
Default – blank = presents <presentation number> <account number>@<module address>. If alternative
information is required by the SIP provider the follow text strings can be used:
%s = presentation number
%c = account number
%u = user
National Prefix
Format of national numbers presented by the SIP provider, eg 0 for UK.
International Prefix
Format of international numbers presented by the SIP provider, eg 00
Country Prefix
Format of the country code presented by the SIP provider, eg 44 for UK
