Splicecom S8000/718 - Phones

Installation and Maintenance Manual
Field Descriptions
350 Installation and Maintenance Manual v4/0615/10
Flash LED
The Flash LED button will instruct the VCM’s SpliceCom LED to flash 20 times.
Product Version
Software version running on this module.
Call Server
Name of the Call Server to which the VCM is registered.
Phones
Analogue extension port
POTS Phone page
Name
64 Domain Characters. The name of this port.
Description
128 Characters. Text description for this port.
Location
To provide Location Text Information for SNMP
Product Version
Not applicable
Caller Display Type
None
Call Display information will not be sent to the extension and the extension will not
ring once after the relevant Phone Module has been rebooted
Default
PCS 10 (suitable for most analogue handsets)
Alarm
For use with alarm systems, DTMF is not sent out but allows the alarm system to send
DTMF tones back out.
Bell
USA
BT
UK
BTNoMessages
For use with InterQuartz Discovery analogue phones
DTMF
Europe
Fax
For use with a fax machine connected to this port, provides a strong/robust ring tone
improving the fax machine’s ability to answer a call
FaxServer
For Fax Server support
Lamp
For use with a PCS 505 or PCS 5 to support the message waiting lamp
Interquartz
For use with InterQuartz Gemini analogue phones
Pay Phone
For use with a pay phone
PCS 10
For use with the PCS 10
PCS 10 Lamp
For use with a PCS 10 to support the message waiting lamp
System Phone
For use with the PCS 520, ensures CLI information is displayed correctly and enables
paging and auto answer functionality
Trunk
Sends a disconnect signal to the end device.
