Caller Display Type
None – Call Display information will not be sent to the extension and the extension will not ring once
after the relevant Phone Module has been rebooted
Default – PCS 10 (suitable for most analogue handsets)
Alarm – for use with alarm systems, DTMF is not sent out but allows the alarm system to send DTMF tones
back out.
Bell – USA
BT – UK
BTNoMessages – for use with InterQuartz Discovery analogue phones
DTMF – Europe
Fax – for use with a fax machine connected to this port, provides a strong/robust ring tone improving the
fax machine’s ability to answer a call
FaxServer – for Fax Server support, please refer to page 208 for further details.
Lamp – for use with a PCS 5 to support the message waiting lamp
Interquartz – for use with InterQuartz Gemini analogue phones
Pay Phone – for use with a pay phone
PCS 10 – for use with the PCS 10
PCS 10 Lamp – for use with a PCS 10 to support the message waiting lamp
System Phone – for use with the PCS 520, ensures CLI information is displayed correctly and enables
paging and auto answer functionality
Trunk – Sends a disconnect signal to the end device.
Caller Display Length
By default the Caller Display Length is set to 0, which means 20 characters will be sent to the handset.
Change this length when more or less characters are required. Set to 16 for the PCS 10.
The information sent will display the Caller information and then the Destination information, eg John
Barrow – Support. The destination uses the first word of, eg the User name, and remaining characters
are used for the Caller’s information.
Partner Login Code
A 1-8 digit access code, eg 1234, is required in this field:
x To enable a PCS 60 or PCS 50 to be partnered to this port.
x If this port is assigned to or will be log on to by a User configured as a Vision Call Centre Agent
and/or will be using the Vision Supervisor Console software. This entry must match the User’s
Remote Working Code. For further information please refer to the Vision Call Centre configuration
manual.
x If this port is assigned to a User configured to utilize the Vision Mobility application. This entry must
match the User’s Remote Working Code. For further information please refer to the Vision
Installation and Configuration manual.
Offhook Working
Tick this box if a headset is used in conjunction with the phone connected to this port. This feature allows
the use of a headset without picking up the receiver by using either Navigate or PCS60 to control the call.
Page Port
This field is used to determine the functionality of this analogue port. Select one of the following three
options:
