SPORTSTECH F17 - Parts List

32
PARTS LIST
Part Description Qty.
1 alignment jig assembly 1
2 main frame assembly 1
3 upright frame assembly-Left 1
4 upright frame assembly-right 1
5 Display frame assembly 1
6 motor holder 1
7 speaker pressing plate 2
8 washer, M10 Ø10.5*Ø20*T1.5 2
9 hexagon check nut, M10 2
10 socket cap screw, M8×100 1
11 socket cap screw, M8×40 1
12 socket cap screw, M8×35 1
13 socket cap screw, M8×55 3
14 socket cap screw, M8×25 2
15 Half-round hexagon screw.,
M8×25
2
16 Half-round hexagon screw.,
M8×35
2
17 Half-round hexagon screw.,
M8×40
2
18 Half-round hexagon screw.,
M6×308.8
6
19 Half-round hexagon screw.,
M6×208.8
2
20 Half-round hexagon screw.,
M6×12 8.8
4
21 Outer hexagonal screw, M8*80 2
22 Cross head self-tapping screw,
ST3*8
17
23 Inner hexagon countersunk head
screw, M6×20
6
24 Inner hexagon countersunk head
screw, M8×25
2
25 spring washer, Ø8 2
26 plate washer, M8 8.5* Ø17*T1.5 10
27 hexagon check nut, M8/ 5
28 Cross countersunk head tapping
screw, ST4*15
2
29 Cross round head screw with
washe, M4*12
2
Part Description Qty.
30 Cross round head screw, M5*15 4
31 Cross head self-tapping screw,
ST3.5*15
6
32 Cross head self-tapping screw,
ST4*16
55
33 Cross head self-tapping screw,
ST4*14
16
34 Cross head self-tapping screw,
ST4*12
4
35 Cross head self-tapping screw,
ST4*25
2
36 Cross head self-tapping screw,
ST5.0*20
4
37 Cross head self-tapping screw,
ST4*16
15
38 tension spring, Ø14*Ø2.0*43 1
39 fixed pin, Ø16*Ø12*40 2
40 spring, Ø15*Ø1.0*45 2
41 front roller,
Ø80*Ø42*Ø15*485*506
1
42 back roller, Ø38*430/Ø12*485 1
43 DC motor, 0.65HP500MM,
330MM
1
44 display, LED (1.0-10Km/H USB
(HRC)
1
45 signal line upper, 550mm 1
46 signal line lower, 1600mm 1
47 controller 1
48 loudspeaker 2
49 safety lock holder 1
50 MP3 input end 1
51 USB port 1
52 AC connecting line, 250MM, 1
53 AC connecting line, 200mm 1
54 power cable, 1800MM,0.75m 1
55 Switch, 6A/250V 1
56 power socket 1
57 oil pipe 1
58 running deck, T12*1080*540 1
59 running belt, T1.6*2425*410 1
