SprayTECH 1420 - Sprayer and Gun Diagrams and Chart; Sprayer and Gun Diagrams; Spray Gun;Tip Chart

5
English
Components and Description
1620
1720
1920
GX-07
GX-07
GX-08
415
517
517
517
519
521
Yellow (fine)
1420 GX-05 415 415 Yellow (fine)
White (medium)
White (medium)
25 feet
25 feet
50 feet
50 feet
This pump is available in a stand model (1420) and cart models (1620, 1720 shown below, and 1920). All information given
f
or the stand model applies to the cart models except where indicated.
*Saddle seat and washer
come pre-assembled
inside spray guard
Saddle
seat*
Washer*
Oiler (1620, 1720
and 1920 only)
Spray hose port
(reverse side)
Pail bracket
Oiler button
Pusher stem
Suction set filter
Suction tube
Return tube
Clip
Hose bracket
PRIME/SPRAY knob
ON / OFF switch
Cord wrap / Tip holder (1620,
1720 and 1920 only)
Toolmate™ Tool box
(1720 and 1920 only)
Spray hose
Spray gun (see chart above
for models, GX-07 shown)
Spray guard
Spray tip (see
chart above
for models)
**The pump cleaning
adapter can be clipped
to the spray hose port
Pump cleaning
adapter**
Pressure control dial
(rear of sprayer)
Important
Some of the graphics in this manual may not exactly match your sprayer and spray gun. All information and instructions
given in this manual applies to all models except where noted.
