Step 2 (Figure 7):
 rotate the top part in the desired direction then slowly put it down ensuring the coaxiality
between the bottom part and the displacer;
 tighten the stud bolts (G);
 remove the hanging equipment and remove the top locking device (A-C-D);
 repositioning the ¾’’ NPT vent cap;
 unscrew for seven turns the stop dowel (F).
Figure 7: TOP part orientation – Step 2
//
G
F
D
C
A
