Step 2 (Figure 19):
screw for seven turns the stop dowel F in order to block the sensor mechanism.
Step 3 (Figure 19):
for instrument having bottom part, screw the stud bolt A into the nut B until it stops;
insert the washer C into the stud bolt and screw the nut D until the contact with the washer
is reached.
Figure 19: transport security operations - Steps 2 & 3
