ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
30
Close levels installation example
LEVEL 3
LEVEL 2
Lowest level slowdown flag.
Slowdown flag upward Level 2.
Slowdown flag upward Level 3.
DR:Slowdown distance
LOWEST LEVEL
Slowdown flag downward Level 2
Slowdown flag downward Level 3.
Slowdown flag upward Level 4.
Close Levels 2 ó 3
224SP
RBRH
224SP READER
(FACE UP)
OR
MAGNETIC SENSORS
RB : Lower end slowdown
two-states magnet
