ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
4
2 BRAKING RESISTOR
MACHINEROOM
Safety area : a minimum 1 meter free space shall be created around the braking resistor.
Caution : the braking resistor may produce a very intense heat. Keep away any flammable
material to avoid fire hazard.
Braking resistor
Electrical cabinet
