ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
11
6 GEARLESS MOTOR
Encoder’s wiring
o The encoder’s cable shall be separated from power cables.
o Connect the encoder’s shield in the VVVF inverter (dedicated flange).
o Connect the motor’s shield on both sides , motor and cabinet.
Supported encoders : SinCos / EnDatsincos.
Wiring :
Terminal
VW3A3409
0
V+
CL-
CL+
D-
D+
S-
S+
C-
C+
Heidenhain
encoder
(0V UN)
(5VUP)
(CLOCK-)
(CLOCK)
(DATA-)
(DATA+)
(B-)
(B+)
(A-)
(A+)
Other encoders
UN
(GND)
UP
(5V)
CLOCK-
(C-)
CLOCK+
(C+)
DATA-
(D-)
DATA+
(D+)
B-
B+
A-
A+
Carte / Board VW3A3409
GND
+5V
CLOCK-
CLOCK+
DATA-
DATA+
B-
B+
A-
A+
