Mandatory settings
Make these settings in Emergency or Temporary operation
+
+ …
Remove the VVVF parameter’s protection
…
Choose « NO »
Choose the type of your encoder.
Set the encoder’s power supply voltage
Set the encoder’s pulses per revolution
CONFIGURATION
FREQ. INVERTER
MENU VF PROTECT.
PROTECTED
MENU VF PROTECT.
NOT PROTECTED
FREQ. INVERTER
ENCODER DATA
REVERSE ROTATION
NO
SUPPLY VOLTAGE
5 V
SUPPLY VOLTAGE
xx V
RESOLUTION
2048
RESOLUTION
xxxx
EMERGENCY OPERA
Choose
CONFIGURATION
ENCODER TYPE
ENDATSINCOS
ENCODER TYPE
xxxxxxx
ENTER
ENTER
ENTER
ENTER
 -
 -
 -
 -
 -
 +
 -
 -
 -
