ASP 116 EVOLUTION INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
36
If you can’t reach the upper floor from the roof of the car, move up to the inspection’s upper
end limit switch and save this position for the last floor. Do not move the car anymore, get out
on the floor, measure the distance from the car to this latest floor and then add this value for
the last floor in the following menu:
« FLOORS POSITION ».
+
+
+
Adjust the heights of the floors :
CONFIGURATION
READER
LEVEL 00
2,000m
LEVEL 00
XXXX m
EMERGENCY OPERA
Choose
CONFIGURATION
READER
FLOORS POSITION
LEVEL 32
112,000m
LEVEL 32
XXXX m
ENTER
ENTER
ENTER
ENTER
-
+
-
-
-
-
-
-
-
