Operators manual MODEL 80XX Planter
page 110 of 173
Options
Drawbar Assembly
PARTS
Pos. Quantity Part # Description
1 1 193108 DRAWBAR,PLANTER,80XX,2006
2 1 193336 DRAWBAR,SHORT,80XX,2006
3 2 193110 PIN,1-5/8"OD,15"LNG
4 1 981263 HITCH,DRAWBAR,200-470HP
5 1 173501 SENSOR,BRACKET,DRAWBAR, 80XX,2006
6 1 602530 CYLNDR,TIE,ROD,5"x8"x20-1/4"
7 1 B94.01675 SENSOR,PROXIMITY,M18,NAMUR
8 1 050211 PIN,CYLNDR,DRAWBAR 80XX,2006
9 1 193107 DRAWBAR,ADJUSTMENT,80XX,2006
10 2 502671 NUT,ACME,1-1/2"-4,RH,THREAD
11 1 193109 DRAWBAR,MOUNTING,BRACKET,80XX,2006
12 1 173502 WRENCH,2.25 INCH
13 4 173323 PLATE,CLAMP,DRWBR 80XX-2005
14 3 050016 SHAFT DRAWBAR MDL 80XX
15 1 192017 CONNECTING LINK DRAWBAR MDL 80XX
16 1 192016 FRAME BRACKET LH DRAWBAR MDL 80XX
17 1 192015 FRAME BRACKET RH DRAWBAR MDL 80XX
