Operators manual MODEL 80XX Planter
page 19 of 173
Seed Level in Bowl –
If there is not adequate seed in the bowl, skips will result. Adjust eh sensor on top of the bowl. The
maximum seed level should be one inch below the top edge to the seed weight door at the rear. The bowl
level should be observed while planting because the bowl may over fill when stopping or lifting the planter.
Speed of Feed Chains –
Mechanical drive is adjusted from the tractor. Hydraulic drive is adjusted manually from the valve located
on the back of the planter.
Specifications
Model 8040 8060 8080
Weight: 9,000 lb.
7,000 to 8,000 lb.
13,500 18,000
Hopper Capacity: 11,000 to 12,000 lb. 15,000 to 16,000 lb.
Configuration and Functions of the Planter
