Operators manual MODEL 80XX Planter
page 148 of 173
Attachments
Chemical Boxes
8040 8060 8080
Pos. Quantity Part # Description
1 2 3 4 981461 ASSY,HOPPER 2-DROP W/15MM RTRS MICROBAND
2 2 3 4 172396 CLAMP MICROBAND MODEL 8060
3 2 3 4 192656 BRACKET BOX SUPPORT MICROBAND 8060
4 2 3 4 192687 PLATE
5 2 3 4 172664 HEX,TUBE MICROBAND DRIVE SHAFT X 6'
6 1 1 1 821718 SHFT,DK,1-1/4"x9-5/16"(2.875-1.25)D3/8"
7 1 1 1 172167 PLATE, MICROBAND DRIVE WASHER
8 1 1 1 181790 CLUTCH,MOUNT PLANTER CHEM BOX DRIVE
9 1 1 1 781351 CLUTCH,12VDC ELEC. WARNER GT I-5215-121
10 4 4 4 231171 HOUSING,BRNG,3HOLE,62MM,FLANGETTE PLATED
11 2 2 2 231071 BRNG,INSERT,1-1/4" BORE SPHR OD VS-120S
12 1 1 1 132177 ASSY,SEED SPACING SPROCKET HUB
13 1 1 1 502445 WASHER,WAVY,1.62 SSR-0162
14 2 2 2 981457 SHIM,1.625"OD x .150"WALL x .024"THICK
15 1 1 1 502446 PIN,LINCH,5/16"OD x 1-9/16"LG W/RING
16 2 2 2 172170 SPACER,TUBE CLUTCH LINKAGE
17 1 1 1 172169 PLATE,SLOTTED CLUTCH LINKAGE
PARTS
