Spudnik 8080 - Cable Harness Schematics; 6-Row Prof. Control Cable Harness Connections

Wereserveallrightsinthisdocumentandintheinformation
containedtherein.Reproduction,useordisclosuretothirdparties
withoutexpressauthorityisstrictlyforbidden.©SPUDNIKEQUIPMENT
SPUDNIKEQUIPMENTCOMPANYLLC
100N584W
BLACKFOOT,ID,83221
www spudnik com
Sheet
Status
change
Proved
User
date
date
name
Sh.
REV1
REV2
WHEEL/BELTENCODERWITHM12CONNECTOR/LENGTHCHANGED
CHANGEDCONA/Bto45°
402758
6ROWPROF.CONTROLCABLEHARNESS
9
02/02/07
HN
HN
HN
HN
08/01/06
08/04/06
15
2 3 GND
Female
6
1 4
87
2 3
9
5
RS232
31/C15 B39 B38
3 2 1
BU
RADAR
/GPS
+12V/C16 B25 31/C15
3 2 1
BU
SK P
SENSOR
1
+12V/C16 A23 31/C15
1 2 3
FEED
CHAIN
2
B8 31/B12 NC
BU
4 3 2 1
STEERING
VALVES
B11 31/B12 B13 31/B12
1 2 3
FEED
CHAIN
3
B10 31/B12 NC
3 2 1
BU
SKIP
SENSOR
2
+12V/C16 A24 31/C15
1 2 3
FEED
CHAIN
1
B7 31/B12 NC
BU
4 3 2 1
FERTILIZER
ENCODER
+12V/C16 C32 31/C34 NC
1 432
M12x1
BIN
SENSOR
1
+12V/C16 NC 31/C15 A13
1 432
M12x1
BIN
SENSOR
2
+12V/C16 NC 31/C15 A16
A9 31/A10
CHEMICAL
CLUTCH
1 432
M12x1
WORK
POS.
B35 31/C15 NC NC
/10.
1 432
M12x1
WHEEL
ENCODER
+12V/C16 A25 31/C15 NC
1 432
M12x1
BELT
ENCODER
+12V/C16 A26 31/C15 NC
CONB CONB
CONC
2 1
BU
C40 31/C15
RTC
SENSOR
2 1
BU
A4 31/A12
FLOWCONTROL
FERTILIZER
2 1
BU
C2 31/C18
SHAKER
1
2 1
BU
C4 31/C18
SHAKER
2
4" 13" 4" 24" 13"
80" 66" 60" 8" 6" 4" 48" 204" 90" 24" 10" 10" 32"36"
27"
13"
60"84"80" 240"
27"
