Spudnik 8080 - Extension Harness Schematics; 8-Row Prof. Control Extension Harness Connections

Wereserveallrightsinthisdocumentandintheinformation
containedtherein.Reproduction,useordisclosuretothirdparties
withoutexpressauthorityisstrictlyforbidden.©SPUDNIKEQUIPMENT
SPUDNIKEQUIPMENTCOMPANYLLC
100N584W
BLACKFOOT,ID,83221
www spudnik com
Sheet
Status
change
Proved
User
date
date
name
Sh.
402759
8ROWPROF.CONTROLEXT.HARNESS
11
02/02/07
HN
HN
15
1 2 3
1 2
FEED
CHAIN
7
C26 31/B36 NC
3 2 1
BU
SKIP
SENSOR
7
+12V/C16 B26 31/C15
1 432
M12x1
BIN
SENSOR
7
+12V/C16 NC 31/C15 B19
1 2 3
1 2
FEED
CHAIN
8
C27 31/B36 NC
3 2 1
BU
SKIP
SENSOR
8
+12V/C16 B34 31/C15
1 432
M12x1
BIN
SENSOR
8
+12/C16 NC 31/C15 B22
1 432 5 876
6 7 8
5
4 32
1
C26 C27 C11 C13 31/B26 31/C21 NC NC
1 432 5 6
6 4 5
1 2 3
B19 B22 B26 B34 31/C15 +12/C16
2 1
BU
C11 31/C21
SHAKER
7
2 1
BU
C13 31/C21
SHAKER
8
90"60"84"90"60"84"
27"
13" 27"
12"
12"
