Spudnik 8080 - 8-Row Low Cost Harness Connections

Wereserveallrightsinthisdocumentandintheinformation
containedtherein.Reproduction,useordisclosuretothirdparties
withoutexpressauthorityisstrictlyforbidden.©SPUDNIKEQUIPMENT
SPUDNIKEQUIPMENTCOMPANYLLC
100N584W
BLACKFOOT,ID,83221
www spudnik com
Sheet
Status
change
Proved
User
date
date
name
Sh.
402760
6ROWLOWCOSTHARNESS
13
02/02/07
HN
HN
15
1 432
6 78
5
4 3 2
1
5 876
8ROW
CONNECTION
P47 P57 P48 P58 NC NC NC NC
1 432
6 4 5
1 2 3
5 6
8ROW
CONNECTION
P113 P114 GND P115 P116 GND
BATTERY
POWER
+12VAWG12 GNDAWG12
INLINEFUSE40A
RINTERMINAL
10mm
1 2 3
1 2
FEED
CHAIN
4
P44 P54 NC
1 2 3
1 2
FEED
CHAIN
5
P45 P55 NC
1 2 3
1 2
FEED
CHAIN
6
P46 P56 NC
/12.
1 432
M12x1
B N
SENSOR
3
P16 NC GND P15
1 432
M12x1
BIN
SENSOR
4
P18 NC GND P17
1 432
M12x1
BIN
SENSOR
5
P110 NC GND P19
1 432
M12x1
B N
SENSOR
6
P112 NC GND P111
84"85"84"80"84"90"84" 360"
13" 27" 13" 27" 13" 27" 18"
