Status/ Diagnostics
(Continued from the previous page)
Press the scroll down button
once to view the next display
Press the scroll down button
once to view the next display
(Continued on the next page)
This section displays the dry fertilizer box encoder status of
the clutch.
This section displays the chemical box clutch status.
CP600 CONTROL BOX
