Operators manual MODEL 80XX Planter
page 86 of 173
Standard Parts
Stone Furrow Openers
PARTS
Pos. Quantity Part # Description
132595 STONE FURROW OPENER 80XX
1 1 192341 FURROW OPENER LONG MODEL 80XX
2 1 192594 BLADE OPENER 80XX
3 1 193373 PLATE FURROW OPENER RH MODEL 80XX
4 1 193374 PLATE FURROW OPENER LH MODEL 80XX
5 2 173462 SHOE,EXTENSION,80XX,2006
6 1 173217 TUBE 80XX STONE FURROW OPENER
7 2 173221 STRAP FURROW OPENER MODEL 80XX
8 2 173228 ARM FURROW OPENER TOP MODEL 80XX
9 2 173232 ARM FURROW OPENER BOTTOM MODEL 80XX
10 2 097.00105 TENSION SPRING [8-58-250]
11 2 090083 TUBE
12 1 173218 TUBE
13 1 173219 TUBE
14 4 231268 BRNG,JOURAL,FLNG,BRONZE.627ID.879OD.75L
15 2 502674 BOLT,BUTTON,HD,5/8"-11UNC x 2" GR 5
16 6 501275 NUT,LOCK,HEX,5/8"-11UNC NYLON INSERT
17 4 502242 SCREW,FLAT,SCKT,HD,3/8"-16 x 1-1/4"
18 2 502306 BOLT,HEX,HD,5/8"-11UNC x 11" GR 5
19 2 502305 BOLT,HEX,HD,5/8"-11UNC x 10" GR 5
