Operators manual MODEL 80XX Planter
page 88 of 173
Standard Parts
Row Unit Group
Pos. Quantity Part # Description
1 2 088.00514 LIMITING DISC [5x340]
2 1 100.43497 PULLEY [x]
3 2 B96.00247 SLIDE BEARING BUSH MSM-2532-20 [x]
4 1 B99.02688 SHIM,40X50X1
5 2 B99.02613 SNAPR.,40X1.75, EXT., DIN471
6 2 057.03749 BEARING RING [80x8x26]
7 2 B96.00088 DEEP GROOVE BA BEARING 6008-2 [40-68-15]
8 2 088.00724 PULLEY [1x78x41]
9 1 B99.02434 LINCH PIN GAL 8X45 [8x45]
10 1 060.02961 AXLE TUBE [40x6x360]
12 2 037.03067 U-BOLT M16 GAL [16x518]
13 1 B99.02340 SPRING SLOTTED PIN DIN1481-6X6 [6x60]
14 1 088.01125 EXCENTRIC DISC
15 2 B96.00246 TWO HOLE FLANGE BEARING RAT20 [x]
16 1 037.03114 AXLE SHAFT [19,98x320]
17 2 B99.01924 SET SCREW M12X20 DIN915 [12x20]
18 1 088.00830 PULLEY [68]
19 1 015.37882 COVER PLATE LH
20 1 018.00927 SCRAPER
21 1 015.37883 COVER PLATE RH
22 2 099.00162 HHC-SCREW M10X190 [10x190]
23 2 B99.02617 RETAINING RING A 50X2 DIN471 [50x2]
24 1 015.31088 BRACKET RH GL34 01 500-1(42)
25 2 037.03995 BOLT [8x120]
26 2 097.00129 PRESSURE SPRING [4-20-102]
27 2 097.00128 PRESSURE SPRING [6-33-110]
28 2 019.00840 COVER [1,5x48]
