SPX FLOW Universal 3 Series User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 127
Standard Seal Kits - 006, 015, 018, 030, 040-U3
Notes:
015U3 kits apply to 006-, 015-, and 018-U3.
030U3 kits apply to 030- and 040-U3
Seal kits include (item numbers from page 126 and from the pump parts list pages): 151, 153, 154, 156, 157, 162, 163/166,
164/171, 165, 36, and 26A
For seal kit nomenclature, see page 129.
Abbreviation Key:
SM Single Mechanical
DM Double Mechanical
C Carbon
SC Silicon Carbide
TC Tungsten Carbide
NF Narrow Face
Description Kit Part# Description Kit Part#
SEAL KIT, 015U3, SM, C/SC, FKM 139357+ SEAL KIT, 030U3, SM, C/SC, FKM 139387+
SEAL KIT, 015U3, SM, C/SC, EPDM 139358+ SEAL KIT, 030U3, SM, C/SC, EPDM 139388+
SEAL KIT, 015U3, SM, C/SC, FFKM 139359+ SEAL KIT, 030U3, SM, C/SC, FFKM 139389+
SEAL KIT, 015U3, SM, SC/SC, FKM 139360+ SEAL KIT, 030U3, SM, SC/SC, FKM 139390+
SEAL KIT, 015U3, SM, SC/SC, EPDM 139361+ SEAL KIT, 030U3, SM, SC/SC, EPDM 139391+
SEAL KIT, 015U3, SM, SC/SC, FFKM 139362+ SEAL KIT, 030U3, SM, SC/SC, FFKM 139392+
SEAL KIT, 015U3, SM, SC/TC, FKM 139363+ SEAL KIT, 030U3, SM, SC/TC, FKM 139393+
SEAL KIT, 015U3, SM, SC/TC, EPDM 139364+ SEAL KIT, 030U3, SM, SC/TC, EPDM 139394+
SEAL KIT, 015U3, SM, SC/TC, FFKM 139365+ SEAL KIT, 030U3, SM, SC/TC, FFKM 139395+
SEAL KIT, 015U3, SM, TC/TC, FKM 139366+ SEAL KIT, 030U3, SM, TC/TC, FKM 139396+
SEAL KIT, 015U3, SM, TC/TC, EPDM 139367+ SEAL KIT, 030U3, SM, TC/TC, EPDM 139397+
SEAL KIT, 015U3, SM, TC/TC, FFKM 139368+ SEAL KIT, 030U3, SM, TC/TC, FFKM 139398+
SEAL KIT, 015U3, DM, C/SC-C/SC, FKM 139369+ SEAL KIT, 030U3, DM, C/SC-C/SC, FKM 139399+
SEAL KIT, 015U3, DM, C/SC-C/SC, EPDM 139370+ SEAL KIT, 030U3, DM, C/SC-C/SC, EPDM 139400+
SEAL KIT, 015U3, DM, C/SC-C/SC, FFKM/FKM 139371+ SEAL KIT, 030U3, DM, C/SC-C/SC, FFKM/FKM 139401+
SEAL KIT, 015U3, DM, C/SC-C/SC, FFKM/EPDM 139372+ SEAL KIT, 030U3, DM, C/SC-C/SC, FFKM/EPDM 139402+
SEAL KIT, 015U3, DM, SC/SC-C/SC, FKM 139373+ SEAL KIT, 030U3, DM, SC/SC-C/SC, FKM 139403+
SEAL KIT, 015U3, DM, SC/SC-C/SC, EPDM 139374+ SEAL KIT, 030U3, DM, SC/SC-C/SC, EPDM 139404+
SEAL KIT, 015U3, DM, SC/SC-C/SC, FFKM/FKM 139375+ SEAL KIT, 030U3, DM, SC/SC-C/SC, FFKM/FKM 139405+
SEAL KIT, 015U3, DM, SC/SC-C/SC, FFKM/EPDM 139376+ SEAL KIT, 030U3, DM, SC/SC-C/SC, FFKM/EPDM 139406+
SEAL KIT, 015U3, DM, SC/TC-C/SC, FKM 139377+ SEAL KIT, 030U3, DM, SC/TC-C/SC, FKM 139407+
SEAL KIT, 015U3, DM, SC/TC-C/SC, EPDM 139378+ SEAL KIT, 030U3, DM, SC/TC-C/SC, EPDM 139408+
SEAL KIT, 015U3, DM, SC/TC-C/SC, FFKM/FKM 139379+ SEAL KIT, 030U3, DM, SC/SC-C/SC, FKM 139409+
SEAL KIT, 015U3, DM, SC/TC-C/SC, FFKM/EPDM 139380+ SEAL KIT, 030U3, DM, SC/TC-C/SC, FFKM/EPDM 139410+
SEAL KIT, 015U3, DM, TC/TC-C/SC, FKM 139381+ SEAL KIT, 030U3, DM, TC/TC-C/SC, FKM 139411+
SEAL KIT, 015U3, DM, TC/TC-C/SC, EPDM 139382+ SEAL KIT, 030U3, DM, TC/TC-C/SC, EPDM 139412+
SEAL KIT, 015U3, DM, TC/TC-C/SC, FFKM/FKM 139383+ SEAL KIT, 030U3, DM, TC/TC-C/SC, FFKM/FKM 139413+
SEAL KIT, 015U3, DM, TC/TC-C/SC, FFKM/EPDM 139384+ SEAL KIT, 030U3, DM, TC/TC-C/SC, FFKM/EPDM 139414+
SEAL KIT, 015U3, SM SC/SC NF, FKM 139554+ SEAL KIT, 030U3, SM SC/SC NF, FKM 139568+
SEAL KIT, 015U3, SM SC/SC NF, EPDM 139555+ SEAL KIT, 030U3, SM SC/SC NF, EPDM 139569+
SEAL KIT, 015U3, SM SC/SC NF, FFKM 139556+ SEAL KIT, 030U3, SM SC/SC NF, FFKM 139570+
SEAL KIT, 015U3, SM, TC/TC NF, FKM 139557+ SEAL KIT, 030U3, SM, TC/TC NF, FKM 139571+
SEAL KIT, 015U3, SM, TC/TC NF, EPDM 139558+ SEAL KIT, 030U3, SM, TC/TC NF, EPDM 139572+
SEAL KIT, 015U3, SM, TC/TC NF, FFKM 139559+ SEAL KIT, 030U3, SM, TC/TC NF, FFKM 139573+
SEAL KIT, 015U3, DM, SC/SC-C/SC NF, FKM 139560+ SEAL KIT, 030U3, DM, SC/SC-C/SC NF, FKM 139574+
SEAL KIT, 015U3, DM, SC/SC-C/SC NF, EPDM 139561+ SEAL KIT, 030U3, DM, SC/SC-C/SC NF, EPDM 139575+
SEAL KIT, 015U3, DM, SC/SC-C/SC NF, FFKM/FKM 139562+ SEAL KIT, 030U3, DM, SC/SC-C/SC NF, FFKM/FKM 139576+
SEAL KIT, 015U3, DM, SC/SC-C/SC NF, FFKM/EPDM 139563+ SEAL KIT, 030U3, DM, SC/SC-C/SC NF, FFKM/EPDM 139577+
SEAL KIT, 015U3, DM, TC/TC-C/SC NF, FKM 139564+ SEAL KIT, 030U3, DM, TC/TC-C/SC NF, FKM 139578+
SEAL KIT, 015U3, DM, TC/TC-C/SC NF, EPDM 139565+ SEAL KIT, 030U3, DM, TC/TC-C/SC NF, EPDM 139579+
SEAL KIT, 015U3, DM, TC/TC-C/SC NF, FFKM/FKM 139566+ SEAL KIT, 030U3, DM, TC/TC-C/SC NF, FFKM/FKM 139580+
SEAL KIT, 015U3, DM, TC/TC-C/SC NF, FFKM/EPDM 139567+ SEAL KIT, 030U3, DM, TC/TC-C/SC NF, FFKM/EPDM 139581+
PL5060-CH166
