5
Dimensions and Connections
Figure 2 (continued from previous page)
DIMENSIONS IN INCHES
MODEL 300 400 500 600 750 900 1050 1300 1500 1800 2200 2600 3200
VIEW REF. I I I I II II II II II II III III III
A 48 53 53 55 60 60 64 66 80 80 85 85 85
B 39.11/16 46.3/4 46.3/4 47.9/16 52.11/16 52.11/16 56.7/16 57.5/16 69.13/16 69.13/16 73.3/8 73.3/8 82.7/8
C 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4 1.1/4
D 19.7/8 23.3/8 23.3/8 23.13/16 26.5/8 26.5/8 29.9/16 30 34.7/8 34.7/8 38.9/16 38.9/16 46.5/16
E 46 52 52 53 59 59 62 63 66 66 73 73 82
F 39.1/2 45.1/2 45.1/2 45.1/2 53.1/2 53.1/2 53.1/2 53.1/2 53.1/2 53.1/2 59.1/2 59.1/2 59.1/2
G 19.3/4 22.3/4 22.3/4 22.3/4 26.3/4 26.3/4 26.3/4 26.3/4 26.3/4 26.3/4 29.3/4 29.3/4 29.3/4
H — — — — 1.1/4 1.1/4 3.1/4 3.1/4 5.15/16 5.15/16 4.3/8 4.3/8 10.1/2
K 2.7/16 2.7/16 3 3 8 8 8 8 8 8 7.1/4 7.1/4 7.1/4
L 10.13/16 12 12.11/16 13.3/16 13.7/16 13.7/16 13.3/16 13.3/16 15.5/8 15.5/8 17.1/4 17.1/4 17
M 90.1/4 96.15/16 96.15/16 100.7/16 100.11/16 100.11/16 99.13/16 104.13/16 101.7/8 101.7/8 115.7/8 115.7/8 113.3/8
N 98 104 105 108 114 114 113 118 116 116 128 128 125
P 11.3/8 13.3/16 13.3/16 14.3/16 15.3/4 15.3/4 16.3/4 17.3/4 20.3/4 20.3/4 22.1/4 22.1/4 26.1/2
R 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4 7/8 X 1.1/4
S 1.1/2 NPT 1.1/2 NPT 2 NPT 2 NPT 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 4 FLANGE 4 FLANGE 4 FLANGE
T 1.1/2 NPT 1.1/2 NPT 2 NPT 2 NPT 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 4 FLANGE 4 FLANGE 4 FLANGE
WT/LBS 1,360 1,776 1,776 1,978 2,323 2,339 2,816 3,326 5,094 5,094 7,753 7,753 8,963
DIMENSIONS IN INCHES
MODEL 300 400 500 600 750 900 1050 1300 1500 1800 2200 2600 3200
VIEW REF. I I I I II II II II II II III III III
A 1207 1346 1346 1397 1524 1524 1626 1676 2032 2032 2159 2159 2159
B 1008 1187 1187 1208 1338 1338 1434 1456 1773 1773 1864 1864 2106
C 32 32 32 32 32 32 32 32 32 32 32 32 32
D 504 594 594 604 677 677 750 761 886 886 980 980 1177
E 1164 1315 1315 1340 1503 1503 1580 1605 1682 1682 1855 1855 2090
F 1003 1156 1156 1156 1359 1359 1359 1359 1359 1359 1511 1511 1511
G 502 578 578 578 679 679 679 679 679 679 756 756 756
H — — — — 32 32 83 83 151 151 111 111 267
K 62 62 76 76 203 203 203 203 203 203 184 184 184
L 274 305 322 335 341 341 335 335 397 397 438 438 432
M 2293 2462 2462 2551 2557 2557 2535 2662 2588 2588 2943 2943 2880
N 2480 2649 2664 2753 2903 2903 2870 2997 2946 2946 3246 3246 3183
P 289 335 335 360 400 400 425 451 527 527 565 565 673
R 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32 22 X 32
S 1.1/2 NPT 1.1/2 NPT 2 NPT 2 NPT 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 4 FLANGE 4 FLANGE 4 FLANGE
T 1.1/2 NPT 1.1/2 NPT 2 NPT 2 NPT 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 3 FLANGE 4 FLANGE 4 FLANGE 4 FLANGE
WT/KGS 617 806 806 897 1,054 1,061 1,277 1,509 2,311 2,311 3,517 3,517 4,086
