11Caliper Piston Removal
Remove the pad retention bolt.
Place the caliper in a vice with soft jaws, then remove each caliper
body bolt.
Separate the caliper body halves.
Set the heat shield aside.
Remove the caliper o-rings from the outboard side of the caliper.
8
2.5 mm Torque Spec 22 mm
T25 Torque Spec 22 mm
9
10
11
