SRAM code r 2018 User Manual

8Caliper Brake Pad Removal
Caliper Brake Pad Removal
Clamp the bicycle into a bicycle work stand and remove the wheel.
Remove the E-clip from the pad retention bolt.
Remove the pad retention bolt from the caliper.
Remove the brake pads and pad H-spring from the caliper.
NOTICE
If the brake pad thickness is less than 3 mm then replace the pads.
1
Needle Nose Pliers 15 mm Thru Axle
2.5 mm
2
3
Digital Caliper Torque Spec 22 mm
