17Lever Blade Removal
Lever Blade Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Pull the hose boot away from the brake body to expose the
compression nut, then slide the boot down the brake hose.
Remove the hose compression nut.
Pull the brake hose and compression fitting from the brake lever body.
Remove the reservoir cap bolt nearest to the lever blade.
1
